| Operating System | Windows 11 home |
| CPU | Intel® Core™ i7-14700, 65W TDP |
| Chipset | Integrated |
| Graphics | Integrated – Intel® UHD Graphics |
| Storage | 2 x M.2 2280 PCIe Gen4x4, supports 256GB~2TB NVMe™ SSD 1 x 2.5″ SATA 6Gb/s, supports 1TB 7200rpm 7mm HDD |
| Wireless Data Network | Intel® Wi-Fi 6E (Gig+) 2×2 + Bluetooth® 5.3 Wireless Card Intel® Wi-Fi 6 (Gig+) 2×2 + Bluetooth® 5.2 Wireless Card *Bluetooth v5.2 and later version functions to be supported in Windows 11 or later. *WiFi 7 and WiFi 6E 6GHz regulatory may vary among countries. |
| LAN | 10/100/1000 Mbps, 1G Intel® LAN |
| Front(Side) I/O Ports | 1 x USB 3.2 Gen2x2 Type-C 2 x USB 3.2 Gen1 Type-A 2 x USB 2.0 1 x Mic in 1 x Audio Jack |
| Back I/O Ports | 2 x USB 3.2 Gen2 Type-A 1 x USB 2.0 2 x DisplayPort 1.4 1 x Configurable Port 1 x RJ45 LAN 1 x Padlock Ring 1 x Kensington Lock 1 x DC-in |
| Speaker | 喇叭，1W 選配 |
| Power Supply | 150W |
| Dimensions (W x D x H) | 175 x 175 x 44.2 mm |
| Weight | 1.18KG |
| Color | 黑色 |
| Accessories | AC Adapter Driver DVD (non OS SKU only) Power Cord Screw Pack User Manual Wi-Fi Antenna Integrated Speaker (optional) Keyboard & Mouse (optional) Optical Drive (optional) Stand (optional) VESA Mount (optional) |
| Security | Trusted Platform Module (TPM)* *on selected model Trusted Platform Module (Firmware TPM) |
| Certificates | BSMI/CB/CE/FCC/UL/CCC/能源之星/C-Tick/WiFi/RF/VCCI |
